DarwinFPV darwin240 FPV Drone Johnny 5

$199.00

Add to cart
Guarantee safe & secure checkout
Guarantee & safe checkout
23 Feb, 2025 - 03 Mar, 2025
On all order
SKU : 1005003708446975 Categories : , Tag : Brand:

Description

Welcome to DarwinFPV shop.We are the design team from China with rich design experience in the field of FPV racing drone. We aim to provide low-cost and high-performance products for every friend in the world who loves flying. Thank you for choosing our products and wish you a happy and safe flight



Item name: darwin240

Comeswithout battery,charger,receiver or remote control.



DarwinFPV-Johnny 5

Wheelbase:240mm

Framearmthickness:5.5mm

Framekitmaterial:3Kcarbonfiber

DrawinFPV

2207-2400KV

BrushlessMotor

Motor KV:2400KV

Idle Current (Io/10V):0.81A

Lipo Cell:3-4S

Weight:36.4g

Max Continuous Current:32A

Max Continuous Power:765W

Configu-ration:12N/14P

Prop adapter shaft:M5

Bolt holes spacing:16mm

Bolt thread:M3

4IN150A

BLHeli_SESC

F4-50A stack

Continuous current: 50A

Peak current: 60A (10S)

Lithium battery section number: 2-6S

BEC: 5V2A

ESC weight: 10.8g

Firmware: BL_S

Maximum support throttle signal: DSHOT600

Mounting hole: M3 30.5 * 30.5mm



F4FlightController

F4 Flight contro

Lithium battery section number: 3-6S

BEC: 10V 1A, 4.5V, 3.3V

MCU: STM32F405

Gyro: MPU6000/6500

OSD: AT7456E

Firmware: MATEKF405

Weight: 7.2g

Mounting hole: M3 30.5 * 30.5mm

Support barometer, black box

Bluetooth

5.8G40CH800mw

VTXTX805P

Frequency: 5.8G Channels: 40CH

Input voltage: 7V~24V

5V camera supply: 120mA(MAX)—-25mW@12V 5V

camera supply: 200mA(MAX)—-200mW@12V 5V

camera supply: 300mA(MAX)—-600mW@12V 5V

camera supply: 350mA(MAX)—-800mW@12V Extra

features: Smart audio

Power supply: 5V output for Camera

Output power: 25mW/200mW/600mW/800mW

switchable Antenna connector: MMCX

Cable connector: Solder pads

Weight: 8g(excluding antenna)



camera

Resolution: 1500TVL

Lens: 2.1mm

TV System: NTSC & PAL (switchable)

DNR: 3DNR

Min. Illumination: 0.001LUX

Shutter Speed: PAL:1/50~100,000;

NTSC: 1/60~100,000

Wide Power Input: 5-30V

Working Temperature: -20℃ ~ +60 ℃

Weight: 6.0g

Dimension: 19*19*19mm

Gemfan Flash 51466

Material:PC

Mountinghole:5mm

Centerthickness:8mm

Quantity:1pairs

Weight:4g

LipoBattery

Notincluded

Recommend4S



DarwinFPV darwin240 FPV Drone Johnny 5 Quadcopters 240mm 5 Inch F4 OSD 50A BLHeli_S Dshot600 800mW 1500TVLDarwinFPV darwin240 FPV Drone Johnny 5 Quadcopters 240mm 5 Inch F4 OSD 50A BLHeli_S Dshot600 800mW 1500TVLDarwinFPV darwin240 FPV Drone Johnny 5 Quadcopters 240mm 5 Inch F4 OSD 50A BLHeli_S Dshot600 800mW 1500TVLDarwinFPV darwin240 FPV Drone Johnny 5 Quadcopters 240mm 5 Inch F4 OSD 50A BLHeli_S Dshot600 800mW 1500TVLDarwinFPV darwin240 FPV Drone Johnny 5 Quadcopters 240mm 5 Inch F4 OSD 50A BLHeli_S Dshot600 800mW 1500TVLDarwinFPV darwin240 FPV Drone Johnny 5 Quadcopters 240mm 5 Inch F4 OSD 50A BLHeli_S Dshot600 800mW 1500TVLDarwinFPV darwin240 FPV Drone Johnny 5 Quadcopters 240mm 5 Inch F4 OSD 50A BLHeli_S Dshot600 800mW 1500TVLDarwinFPV darwin240 FPV Drone Johnny 5 Quadcopters 240mm 5 Inch F4 OSD 50A BLHeli_S Dshot600 800mW 1500TVLDarwinFPV darwin240 FPV Drone Johnny 5 Quadcopters 240mm 5 Inch F4 OSD 50A BLHeli_S Dshot600 800mW 1500TVL

Additional information

Weight 28 kg
Dimensions 9 cm
Brand Name

DarwinFPV

Indoor/Outdoor Use

outdoor

Video Capture Resolution

other

Camera Mount Type

other

Controller Battery

2

Origin

Mainland China

Takeoff Weight

500g

Aerial Photography

Yes

Control Channels

6 CHANNEL

Transit Time (Days)

3km

Flight Time

5~10

Controller Mode

MODE2

Recommend Age

14+y

Anti-wind Ability

7

Is Electric

No battery

Material

Carbon Fiber

Drone Weight

351.6g

Remote Distance

1000

Package Includes

Original Box

Remote Control

No

Type

HELICOPTER

Features

App-Controlled
